Air Filter Regulator AW Series with Cover
The Air Filter Regulator AW Series with Cover from CG Pneumatic is a dual-function air preparation unit that ensures clean, dry, and precisely regulated compressed air. This unit integrates both an air filter and a pressure regulator in one compact body—optimized for industrial automation and equipment control systems.
What sets the AW Series with Cover apart is its reinforced protective bowl cover, designed to prevent damage from impact, dust, and external contaminants. The transparent polycarbonate bowl allows for easy monitoring of water levels, while the cover ensures longer service life and added operator safety.
Main features include:
- Combination of filtration and pressure regulation
- Protective cover for enhanced durability and safety
- Compact body for easy installation in tight spaces
- Manual or semi-automatic drain options
- High-precision pressure adjustment for sensitive applications
- Modular compatibility with additional FRL components
Whether used in manufacturing lines, air tools, or machinery systems, the Air Filter Regulator AW Series with Cover provides stable performance and extended protection in harsh environments.
| Parameter | Specification |
|---|---|
| Model | AW1000 / AW2000 / AW3000 / AW4000 / AW5000 |
| Port Size | 1/8″, 1/4″, 3/8″, 1/2″, 3/4″, 1″ |
| Working Pressure | 0.05 – 0.85 MPa |
| Max Pressure | 1.5 MPa |
| Operating Temperature | 5 – 60°C |
| Filter Accuracy | 25 μm standard (optional 5 μm) |
| Bowl Material | Polycarbonate with protective cover (optional metal bowl) |
| Drain Type | Manual or automatic drain (depending on model) |
| Lubricator Type | Oil mist type with adjustable oil delivery |
| Medium | Filtered compressed air only |
