Pneumatic Lubricator AL Series Gold with Cover

About Pneumatic Lubricator AL Series Gold with Cover

Pneumatic Lubricator AL Series Gold with Cover from CG Pneumatic combines precise oil mist delivery with enhanced protection in a compact design. Finished in anodized gold, this lubricator provides consistent lubrication to downstream pneumatic components while offering a high-end appearance for modern equipment setups.

The protective cover safeguards the transparent polycarbonate bowl against dust, debris, and impact, extending service life in demanding environments. Ideal for use in industrial automation, air tool lines, and precision machinery requiring clean and controlled air lubrication.

Key features:

  • Accurate oil mist output for pneumatic tools and systems
  • Anodized gold finish with reinforced bowl cover
  • Adjustable lubrication via stepless needle valve
  • Transparent bowl for quick oil level checks
  • Suitable for AL1500, AL2000 models
SpecificationDetails
Model SeriesAL1500 / AL2000
Color OptionBlack / Gold / White
Port Sizes1/8″, 1/4″
Operating Pressure0.05 – 0.85 MPa (21 – 130 psi)
Maximum Pressure1.5 MPa (215 psi)
Operating Temperature5 – 60°C (41 – 140°F)
Oil Feed AdjustmentStepless needle valve
Bowl MaterialPolycarbonate (cover optional)
MountingBracket or direct mounting

Want to explore more CG pneumatic air source treatment ?Click here: Air Source Treatment Unit to learn more.
